VMC650 cnc milling machine metal
A machining center is an advanced machine tool that can machine a part, usually metal, by removing material. Usually, we refer to milling or machining in a general way.
Product Description
VMC650 cnc milling machine metal
product description:
In vertical machining centers, the spindle is oriented vertically, so the tool is cut from the top of the workpiece.VMC650 cnc milling machine metal allows large parts to be machined by machining all sides of the part without operator intervention. This type of machining is suitable for grinding of molds and machining of tool parts.
Video:
In vertical machining centers, the spindle is oriented vertically, so the tool is cut from the top of the workpiece.VMC650 cnc milling machine metal allows large parts to be machined by machining all sides of the part without operator intervention. This type of machining is suitable for grinding of molds and machining of tool parts.
Video:
Video:
Product Specifications:
| Model | ALVMC650C |
| Travel | |
| X axis | 600mm |
| Y axis | 500mm |
| Z axis | 500mm |
| Distance from spindle nose to table | 100-600mm |
| Distance from spindle center to column | 550mm |
| Worktable | |
| Worktable size | 800×500mm |
| Max. loading capacity | 400kg |
| T-slot | 5×18×90mm |
| Spindle | |
| Speed | 8000rpm |
| Taper | BT40 |
| Main motor power | 5.5Kw |
| Feed | |
| Rapid feed speed | 20m/min |
| Cutting feed speed | 10m/min |
| Positional accuracy | 0.016mm |
| Repeated positional accuracy | 0.006mm |
| X Y Z motor torque | 10/10/15Nm |
| Machine | |
| Weight | 3800 Kg |
| Overall dimensions（L×W×H） | 1900×2310×2300mm |
Video:
