China CNC Milling Machine VMC1580 Fanuc CNC Controller VMC Machine

VMC1580 is widely used in machinery manufacturing, aerospace, automobile, mold and other industries. CNC vertical machining center VMC1580 is a powerful CNC machining center, which is widely used in various machining processes in the machinery manufacturing industry.

Product Description

CNC vertical machining center VMC1580 can be used to process various parts in the automobile manufacturing industry. Through high-precision and high-efficiency processing technology, the performance and quality of automobiles can be improved. CNC milling machine for metal VMC1580 can be used to process various automotive engine parts, such as cylinder blocks, cylinder heads, crankshafts, connecting rods, etc. Through high-speed milling, high-precision drilling and tapping and other processing technologies, parts with high precision and high surface quality can be obtained.

Features of cnc milling machine VMC1580:

1. CNC machining center adopts high-speed feed and positioning system, which can realize high-precision machining and is suitable for machining precision mechanical parts.

2.3 axis cnc vertical machining center VMC1580 has a larger workbench area and can process larger workpieces.

3.China cnc milling machine is equipped with high-speed spindle and cutting tools, which can realize fast cutting and improve production efficiency.

4. 3 axis cnc vertical machining center adopts stable machine tool structure and high-quality mechanical components, which ensures the stability and reliability of the machine tool.

Application fields of cnc milling machine 3 axis:

1. Aerospace: cnc milling machine for metal VMC1580 is used to process parts of various aluminum alloys, titanium alloys and nickel-based alloys, such as aircraft structural parts, engine parts, etc.

2. Automobile manufacturing: cnc milling machine for metal VMC1580 is used to process various auto parts, such as engines, gearboxes, steering systems, etc.

3. Mold manufacturing: CNC vertical machining center VMC1580 is used to process various molds, such as injection molds, die-casting molds, stretching molds, etc.

4. Electronics manufacturing: 3 axis cnc milling machine VMC1580 is used to process parts of various electronic products, such as mobile phone casings, computer radiators, etc.

5. Precision machinery manufacturing: CNC vertical machining center VMC1580 is used to process various high-precision parts, such as precision instruments, optical devices, etc.

Video

Product Specifications

Unit	parameter	VMC1580
Worktable size	mm	1600*800
Maximum load	kg	1000
X axis travel	mm	1500
Y-axis travel	mm	800
Z-axis travel	mm	700
Distance from spindle center to column	mm	855
Spindle speed	rpm	6000
Spindle head casing bore	mm	φ190mm
Tool length	mm	350
Tool weight	kg	15
Positioning accuracy	mm	0.02
Repeatability	mm	0.01
Floor area and height	mm	351531752850
Machine weight	kg	12000
