CNC Milling Machine For Metal VMC1280 is an efficient, precise and multi-functional machine tool equipment, CNC Machining Center is widely used in machinery manufacturing, aerospace, automobile, medical equipment, hardware products and other industries.
Product Description
3 axis cnc vertical machining center equipment adopts imported high-precision linear guide rail and high-precision ball screw, which can realize high-speed, high-precision and high-efficiency machining. 3 axis cnc milling machine VMC1270 can complete milling, drilling, tapping, reaming and other processing tasks, and is suitable for processing various materials, such as aluminum alloy, titanium alloy, stainless steel, copper, etc.
Features of CNC milling machine VMC1280:
1. CNC machining center VMC1280 adopts imported high-precision linear guide rail and high-precision ball screw, equipped with high-performance spindle motor, which can realize fast and high-precision machining. Its maximum moving speed can reach 48 m/min, and its machining accuracy can reach 0.005 mm.
2. CNC milling machine for metal VMC1280 adopts digital control system, equipped with automatic tool change system and automatic detection device, which can realize fully automatic processing operation, greatly improving production efficiency and processing accuracy.
3.3 axis cnc milling machine VMC1280 adopts high-strength cast iron machine bed and optimized structure combination, so that the machine tool has the characteristics of high rigidity, high stability and high precision.
4.China cnc milling machine VMC1280 can realize milling, drilling, tapping, reaming and other processing operations, and can process various materials, such as aluminum alloy, titanium alloy, stainless steel, copper and so on.
5. CNC machining center VMC1280 is suitable for parts processing and mold processing in aerospace, automobile, electronics, machinery manufacturing, medical equipment and other fields.
Application fields of CNC vertical machining center:
CNC Milling Machine For Metal VMC1280 is suitable for various machinery manufacturing and parts processing fields. CNC machining center is widely used in mold manufacturing, aerospace parts processing, auto parts processing, medical equipment manufacturing, hardware processing and other industries.
Video
Product Specifications
Unit
Parameter
VMC1280
3axis travel (X / Y / Z)
mm
1200/800/800
Distance from spindle centerline to column guide surface
mm
550
Table size (length × width)
mm
1300×800
Maximum load
kg
800
Spindle speed
rpm
0~8000
Spindle motor power
kW
11
Maximum tool diameter (no adjacent tool)
mm
120
Maximum drilling diameter (for normalizing medium carbon steel)
mm
25
Maximum tapping diameter (for normalizing medium carbon steel)
