H46 flat bed line rail CNC machine tool can turn various threads, arcs, cones and inner and outer surfaces of rotary bodies, and is widely used in plumbing equipment, valves, electrical appliances, instrument bearings and other industries.
Product Description
H46 Mini lathe machine for metal
product description:
The bed of the linear guide flat bed CNC lathe H46 is the basic support of the entire machine tool and the main body of the machine tool. H46 flat bed CNC lathe is generally used to place important components such as guide rails and spindle boxes. The structure of the bed has a great influence on the layout of the machine tool. Video:
Video:
Product Specifications:
Machine Model
Unit
H46
Max swing over bed
mm
Φ460
Max swing over cross slide
mm
Φ150
Maximum processing length
mm
330
X/Z axis travel
mm
360/330
Spindle nose
Α2-5
Spindle bore
mm
Φ48
Bar Capacity
mm
Φ40
Max. spindle speed
rpm
4000
Spindle motor
kw
5.5
X/Z axis repeatability
mm
±0,003
X/Z axis feed motor torque
N.m
Χ:6 Ζ:6
X/Z Rapid traverse
m/min
15/15
Cutting tool size
mm
25×25
Machine dimension(L×W×H)
mm
2200×1580×1815
Net. weight (about)
kg
2200
Product advantages:
1. The spindle adopts precision spindle unit, with low noise, high speed and long service life.
2. It is driven by a servo spindle, and the output torque is large at low speed. The vertical and horizontal guide rails use precise linear guide rail pairs, which have high positioning accuracy and good stability.
3. Multiple tool holders can be installed at the same time, which saves time for tool change and makes up for the positioning and height errors during rotation.
