CNC Lathe ALCK61100X4000 CNC turning

ALCK61100X4000 Horizontal CNC Lathe is a high-performance CNC machine tool with many outstanding features. The CNC lathe can accurately process the wheel hubs of various vehicles, ensuring their quality and balance, and improving the safety and comfort of car driving.

Product Description

ALCK61100X4000 CNC turning is a multifunctional, high-performance CNC machine tool that is widely used in auto parts manufacturing and other industrial fields, providing high-precision and high-efficiency solutions for the processing of various workpieces. Horizontal CNC Lathe is used to manufacture key components such as engine crankshafts, camshafts, and cylinder blocks to ensure engine performance and reliability.

Features:

1. High-precision processing capability: Horizontal CNC Lathe ALCK61100X4000 adopts advanced CNC technology and has excellent processing accuracy, which can meet the demand for high-precision parts and ensure product quality.

2. Large processing size: The bed size of CNC lathe for metal is spacious, and the maximum processing diameter reaches 4000 mm. It is suitable for processing large workpieces, such as automobile wheels, engine parts, etc.

3. Multi-function processing: ALCK61100X4000 CNC turning supports a variety of processing operations, including turning, boring, drilling, etc., which improves the processing efficiency and flexibility of workpieces.

4. Stability and reliability: CNC lathe for metal adopts high-quality mechanical structure and electronic control system to ensure long-term stable operation and reduce maintenance costs.

5. User-friendly interface: CNC turning CNC operation interface design is intuitive and easy to operate, reducing operator training costs.

CNC lathe ALCK61100X4000 application:

1. Automobile manufacturing industry: CNC turning is an important tool for auto parts manufacturing and is used to process key components such as wheel hubs, crankshafts, camshafts, and gearbox housings.

2. Aerospace industry: CNC lathe for metal is used to manufacture aircraft engine parts, aircraft landing gear, spacecraft parts, etc.

3. Energy field: Horizontal CNC Lathe is used to process large industrial equipment such as power generation equipment and oil drilling rig parts.

4. Railway transportation: CNC lathe for metal is used to process railway wheelsets, railway switch parts, etc.

5. General machinery manufacturing industry: Horizontal CNC Lathe is suitable for manufacturing key components of various general machinery equipment, such as gears, bearing seats, couplings, etc.

Video

Product Specifications

Item	Unit	ALCK61100X4000
Swing over bed	mm	1000
Swing over cross slide	mm	610
Distance between centers	mm	4000
Guideway width	mm	755
Spindle bore	mm	130
Spindle speed range	rpm	4-300
Tool shank size	mm	40x40
X axis travel	mm	520
Z axis travel	mm	3850
X axis rapid traverse	mm/min	4000
Z axis rapid traverse	mm/min	6000
Tailstock quill diameter	mm	160
Tailstock quill travel	mm	300
Main spindle motor	Kw	22
Width x Height	mm	2100x2100
Length	mm	7500
