Specifications | Unit | ALTCK36A |
Max. swing over bed | mm | Φ360 |
Max. swing over cross slide | mm | Φ140 |
Max. processing length | mm | 300 |
The spindle motor power | kw | 3.7 |
Highest spindle speed | rpm | 4000 |
Spindle bore | mm | Φ48 |
Bar capacity | mm | Φ40 |
The X-axis limit stroke | mm | 310 |
The Z axis stroke limit | mm | 350 |
X/Z axis repeatability | mm | ±0.003 |
Machine dimension(L×W×H) | mm | 2200×1600×1850 |
Net. weight (about) | kg | 2400 |
ALLES CNC provides the most innovative manufacturing technology and advanced support resources in the automotive/truck industry. Whether you are machining basic suspension brackets, complex engine parts or off-road parts from heat-resistant stainless steel or cast iron, ALLES CNC turning and milling center can meet your needs to shorten cycle time, produce precision parts and increase productivity.
ALLES CNC provides the most innovative manufacturing technology and advanced support resources in the aerospace industry. Whether you use titanium, heat-resistant super alloys, aluminum or stainless steel to machine structural parts, engine parts, landing gear or system control devices, ALLES CNC turning center metal can meet your requirements for optimizing manufacturing operations, producing the highest quality parts and increasing productivity demand.
ALLES CNC provides the most innovative manufacturing technology and advanced support resources in the medical industry. Slant bed CNC lathe can complete the manufacture of orthopedic equipment such as knee replacement parts, bone screws, hip joint assembly, hip socket, lumbar plate, tibia tray, tibia tray, and customized implants. Surgical instruments such as implant holders, custom fixtures, plate benders, spacers, broaches. Dental and orthodontic implants such as: subperiosteal implants, dental bridges, dental tools
CNC turning center can automatically process the outer circle, inner hole, thread and complex arc surface of mechanical parts with one programming input. The CNC turning and milling center can meet the needs of various manufacturing fields, including energy, petroleum, shipbuilding, structural parts, construction machinery, aerospace, medical, auto repair, diesel engines and heavy machinery.
