TCK46A cnc lathe with slant bed

H46 inclined bed and linear guide CNC lathe is suitable for machining various small and medium shaft and plate workpieces, and can also turn various threads, arcs, conical, inner and outer surfaces of the rotating body.

Product Description

TCK46A cnc lathe with slant bed

product description:

The CNC lathe with inclined bed TCK46A is a kind of automatic machine tool with high precision and high efficiency. TCK46A CNC lathe linear rolling guides meet the requirements of high speed and high efficiency, reduce frictional resistance and temperature rise deformation, improve machining accuracy, and ensure long-term stability of cutting machining accuracy.

Slant Bed And Linear Guide Way CNC Lathe ALTCK46A

Video:

Slant bed CNC lathe ALTCK46A

Video:

Product Specifications:

Item	ALTCK46A
Maximum upper turning diameter of bed	Φ460mm
Maximum machining diameter on tool post	Φ170mm
Maximum processing length	350mm
Spindle head type (optional chuck)	A2-5
Spindle motor power	5.5KW
Spindle speed	3500pm
Spindle hole diameter	Φ56mm
Bar diameter	Φ45mm
X axis limit stroke	240mm
The X/Z axis screw specifications	3210/4010
The X-axis limit stroke	240mm
The Z axis stroke limit	400mm
The X axis motor torque	7.5N.m
The Z axis motor torque	7.5N.m
X/Z axis repeatability	±0.003mm
Maximum stroke of tailstock	200mm
length * width * height (mm)	2500×1700×1890mm
Weight (approximate weight)	2600kg

Product advantages:

1. The linear rolling guide of the CNC lathe with inclined bed meets the requirements of high speed and high efficiency, reduces frictional resistance and temperature rise deformation, improves machining accuracy, and can ensure the long-term stability of cutting machining accuracy.

2. The CNC lathe with inclined bed adopts domestic or imported high-rigidity horizontal turret tool rest, which has high positioning accuracy and small deformation during heavy cutting.

3. Standard configuration: spindle stepless speed regulation, hydraulic chuck, hydraulic tailstock, horizontal eight-station tool rest, closed protection.

4. The CNC lathe with inclined bed adopts the overall inclined bed structure, which can still maintain the stability of the machine tool accuracy during heavy cutting.
